Service Hub // SSR MultiPro Jr.

SSR MultiPro Jr.

Affordable entry into portable rollforming

Open the manual

Panel Profiles:: 7
Max Speed:: 30 ft/min
Power:: Electric
Drive Rollers:: Polyurethane

Engineering Specs Plan View

Machine Footprint Open PDF

Frequently asked

How much does the SSR metal roof panel machine cost?

The SSR MultiPro Jr. starts at $44,900 with one profile included. With a trailer, the EZ-Counter length controller, and a canvas cover, it comes to about $70,900. See the roof panel machine cost guide.

Is the SSR good for beginners?

Yes — the SSR MultiPro Jr. is the most affordable entry point into portable rollforming. It's electric-powered, easy to operate, and produces up to 7 panel profiles.

Why is the SSR less expensive than the SSH or SSQ?

The SSR uses electric power only (no hydraulic drive), has a manual shear, and a smaller footprint. It's designed for residential contractors getting started with on-site panel production.

What profiles can the SSR produce?

Up to 7 profiles including mechanical seam, snap-lock, and snap-lock with slotted flange options.

What warranty is included?

Limited three-year part and NTM in-house labor warranty.

What power does the SSR need?

A 1.5 HP, 120V, 60 Hz single-phase motor drawing 18 amps. A 220V option is available, and a 100-foot, 10 gauge extension cord is included.

How fast does the SSR run?

Up to 30 feet per minute.

What materials and gauges can the SSR run?

Painted steel from 28 to 24 gauge (50 ksi maximum at 24 gauge), painted aluminum from .027" to .040", and 16 to 20 oz. copper. Coil widths run 15" to 20".

How much does the SSR weigh?

The machine weighs 1,715 lbs. (780 kg). On its trailer it weighs 3,975 lbs. (1,800 kg).
