Service Hub // MACH II 6"

MACH II 6" Gutter Machine

Dedicated 6" K-style for larger homes

Open the manual
Max Speed:
50 ft/min
Machine Weight:
1,250 lbs
Years Proven:
30+
Gutter Profile:
6" K-style
Engineering Specs Plan View
MG5 MG6 MG56
Machine Footprint Open PDF

Frequently asked

How much does a 6 inch gutter machine cost?
The MACH II 6" starts at $10,500 for the machine only. Packages with a shear, coil cradles, or reels cost more; our gutter machine cost guide lists every configuration.
Why choose a 6 inch gutter machine over the 5 inch model?
6" gutters handle more water flow and are increasingly popular for larger homes and commercial buildings. If your market demands 6", this is the dedicated machine.
What coil width does the 6 inch gutter machine use?
The MACH II 6" runs 15" (380mm) wide coil. The reel rack holds coil up to 30" in diameter.
What materials can the 6 inch gutter machine run?
Painted steel, Galvalume, and coated galvanized steel from 30 to 24 gauge, painted aluminum from .019" to .032", and 16 oz. to 20 oz. 3/4 hard copper.
How much does the 6 inch gutter machine weigh, and what power does it need?
The machine weighs 1,250 lbs (570 kg) and is 10' long, 2' wide, and 4' high. It runs on a 3/4 HP, 110 VAC, 60 Hz, single-phase motor that draws 11 amps.
How fast is the MACH II 6"?
Up to 50 feet per minute with polyurethane drive rollers.
Can I upgrade to the combo later?
The 5" and 6" are separate machines. If you need both sizes, consider the MACH II 5"/6" Combo from the start.
What profiles are available?
Three 6" K-style profiles: with straight back (MG6-SB6), with Alcoa hook (MG6-HK6), and with bottom bead (MG6-BB6).
What warranty is included?
Limited three-year part and NTM in-house labor warranty.

Machine profiles

Profiles this machine runs.

Open the profile pages for gauges, widths, and setup details tied to this machine.

Manuals · 2

Troubleshooting · 16

Videos · 30
