Service Hub // WAV Wall Panel

WAV

The industry's only portable WAV profile machine

Engineering Specs Plan View

Machine Footprint Open PDF

Frequently asked

How much does the WAV metal panel machine cost?

The WAV starts at $224,500 for the gas-only model, depending on configuration. See the panel machine cost guide.

What profiles does the WAV produce?

Three WAV-style profiles in 16", 12", and 8" widths with either fastener flange or clip-style attachment for commercial wall panel applications.

Does the WAV come with a controller?

Yes — the UNIQ® Automatic Control System comes standard with computer batch and length control.

Is training included?

Yes — free on-site setup and training within the continental U.S. is included with every WAV purchase.

Is the WAV a roof panel machine?

No. The WAV is a wall panel machine built for heavy commercial and industrial walls. For standing seam roof panels, look at the SSQ3 MultiPro.

How fast does the WAV run?

Up to 150 feet per minute on electric power and up to 75 feet per minute on gas.

What materials can the WAV run?

22 or 24 gauge Grade 50 painted steel. Painted aluminum from .032" to .040" runs on the WAV-16-4 profile only.

How much does the WAV weigh?

The machine weighs 5,000 lbs. (2,272.7 kg). On its trailer it weighs 8,700 lbs. (3,954.6 kg).

Machine profiles

Open the profile pages for gauges, widths, and setup details tied to this machine.
